Resin Systems
Series17 and 23 - Profile made from a standard polyester isophthalic resin system.
Series17V and 23V - Profile made from a vinylester resin.
Series100 - A fire retardant system certified to achieve BS476:pt7 and EN13501-1 B, S3, D0.
Series100LS - A low smoke fire retardant system certified to achieve BS476:pt7 and EN13501-1 B, S1, D0.
Standards
6m Lengths as standard
Bespoke lengths available upon request to a maximum of 12m
Colours
Black - RAL9005
Brown - RAL8028
Green - RAL6005
Grey - RAL7001
White - RAL9010
Yellow - RAL1004
Other colours are available upon request.
Specification
|
|
|
E23 Grade |
E17 Grade |
|
Full Section Modulus |
GPa |
23 |
17 |
|
Tensile Strength (axial) |
MPa |
240 |
170 |
|
Tensile Strength (transverse) |
MPa |
50 |
30 |
|
Tensile Modulus (axial) |
GPa |
23 |
17 |
|
Tensile Modulus (transverse) |
GPa |
7 |
5 |
|
Flexural Strength (axial) |
MPa |
240 |
170 |
|
Flexural Strength (transverse) |
MPa |
100 |
70 |
|
Inter-Laminar Shear |
MPa |
25 |
15 |
|
Pin Bearing Strength |
MPa |
70 |
50 |
