Resin Systems
Series17 and 23 - Profile made from a standard polyester isophthalic resin system.
Series17V and 23V - Profile made from a vinylester resin.
Series100 - A fire retardant system certified to achieve BS476:pt7 and EN13501-1 B, S3, D0.
Series100LS - A low smoke fire retardant system certified to achieve BS476:pt7 and EN13501-1 B, S1, D0.
Standards
6m Lengths as standard
Bespoke lengths available upon request to a maximum of 12m
Colours
Black - RAL9005
Brown - RAL8028
Green - RAL6005
Grey - RAL7001
White - RAL9010
Yellow - RAL1004
Other colours are available upon request.
Specification
E23 Grade | E17 Grade | ||
Full Section Modulus | GPa | 23 | 17 |
Tensile Strength (axial) | MPa | 240 | 170 |
Tensile Strength (transverse) | MPa | 50 | 30 |
Tensile Modulus (axial) | GPa | 23 | 17 |
Tensile Modulus (transverse) | GPa | 7 | 5 |
Flexural Strength (axial) | MPa | 240 | 170 |
Flexural Strength (transverse) | MPa | 100 | 70 |
Inter-Laminar Shear | MPa | 25 | 15 |
Pin Bearing Strength | MPa | 70 | 50 |
